HM SERIES
PRODUCT OVERVIEW
The HM Series is a premium cast iron industrial motor engineered for continuous-duty operation in demanding environments. Combining high efficiency, rugged construction and internationally certified performance, it helps businesses maximise uptime while reducing energy and maintenance costs.
AVAILABLE POWER RANGE
0.37 kW to 1500 kW
Keep Water Out. Keep Production Moving.
Dust, rain, washdowns and harsh operating environments are a reality across many industries. With IP66 protection, the HM Series is designed to prevent dust ingress and powerful water jets, helping protect the motor and reduce the risk of unplanned downtime.
Why it matters:
✓ Greater protection in harsh environments
✓ Improved operational reliability
✓ Confidence indoors or outdoors
✓ Reduced maintenance requirements
Your investment is well protected with a frame material
made from heavy-duty cast iron.
Built to Handle the Heat.
Electric motors work hard, and heat is the biggest factors affecting motor life. Class H insulation provides a higher thermal tolerance than conventional motor insulation systems, helping the motor operate reliably under demanding conditions.
Why It Matters:
A cooler, better-protected motor is a more reliable motor. By using insulation capable of handling higher thermal loads, businesses benefit from greater operational confidence and reduced risk of unexpected failures.
Longer Motor Life
Heat is one of the leading causes of insulation breakdown. Higher thermal resistance helps extend the life of the winding system, allowing the motor to perform reliably for longer.
Reduced Downtime
Unexpected motor failures can halt production and lead to expensive repairs. Better insulation reduces the risk of heat-related failures, keeping operations running.
Greater Reliability
Demanding environments require equipment that continues performing under pressure. Class H insulation provides additional protection during overloads, frequent starts and high ambient temperatures.
Lower Lifetime Costs
Longer service intervals, fewer failures and reduced maintenance contribute to a lower total cost of ownership throughout the motor's lifespan.
Not sure which Efficiency Class is for you?
Electric motors are responsible for a significant portion of industrial electricity consumption. Choosing the right efficiency class can reduce operating costs, lower energy consumption and improve long-term return on investment. Whether your priority is dependable performance, maximum energy savings or future-ready technology, Electromote offers an efficiency class to suit your application.
IE3 motors deliver an excellent balance between performance, durability and energy efficiency
They are the preferred choice for most industrial applications.
Designed to reduce energy consumption while maintaining dependable operation.
Guaranteed to offer outstanding value for businesses seeking reliable everyday performance.
-
Everyday industrial applications.
-
Excellent balance of performance and value.
IE4 motors are engineered to minimise electrical losses and maximise energy performance.
By converting more electrical energy into useful mechanical power, they help businesses reduce electricity costs over the lifetime of the motor
They are an excellent investment for operations with long running hours.
-
Continuous operation.
-
Lower energy consumption and reduced operating costs.
IE5 technology represents the highest level of motor efficiency currently available.
Delivers exceptional energy savings and superior performance.
IE5 motors are designed for businesses focused on maximising efficiency, reducing carbon emissions and preparing for the future of industrial automation.
-
Maximum efficiency applications.
-
Highest performance with the lowest lifetime energy costs.
Backed for the long run.
Every HM Series motor is supported by a 5-year warranty, providing added peace of mind for businesses that rely on dependable equipment every day. It is our assurance that the quality, durability and performance of this range are engineered for the long haul.
✓ Added peace of mind
✓ Long-term value
✓ Reduced ownership risk
✓ Confidence in demanding applications
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
Multi Voltage
The HM Series is available in 400V, 550V, 690V and 1000V configurations, allowing the motor to integrate seamlessly into a wide range of industrial power networks without compromising performance or reliability.
Vacuum Pressure Impregnation (VPI)
A motor's windings are constantly exposed to vibration, heat, moisture and contaminants. Electromote motors use Vacuum Pressure Impregnation (VPI) to completely seal and protect the stator windings.
Unlike conventional dip varnishing, VPI ensures complete resin penetration throughout the winding, creating a stronger and more durable insulation system.
Fully Processed Lamination Steel (FPLS)
The magnetic core is the heart of every electric motor. Electromote motors are manufactured using Fully Processed Lamination Steel, a premium electrical steel specifically designed to reduce magnetic losses and improve overall motor efficiency.
The result is lower operating temperatures, improved efficiency and reduced energy consumption throughout the motor's lifetime.
The Right Speed Starts with the Right Pole Configuration.
Every industrial application operates differently. Some require high-speed performance, while others rely on slower, high-torque operation.
A motor's pole configuration determines its operating speed, making it one of the most important factors when selecting the right motor.
Choosing the correct number of poles helps maximise efficiency, improve equipment performance and ensure the motor is perfectly matched to its application. The number of poles inside an electric motor directly affects its rotational speed. The HM Series is offered with 2, 4, 6, 8, 10 pole options.
-
Fewer poles = Higher speed
-
More poles = Lower speed, higher torque
Speed Isn't Everything.
The fastest motor isn't always the best choice.
Selecting the correct pole configuration ensures your equipment operates at the intended speed while delivering the torque required by the application. This improves efficiency, reduces wear on mechanical components and helps maximise motor life.
2 Pole
High Speed Performance
Ideal for fans, blowers and applications requiring higher rotational speeds.
Approx. Speed: 2950 rpm
4 Pole
The Industry Standard
Versatile and widely used across pumps, conveyors and general industrial equipment.
Approx. Speed: 1450 rpm
6 Pole
Controlled Operation
Designed for applications requiring lower speeds and increased torque.
Approx. Speed: 950 rpm
8 Pole
Heavy-Duty Performance
Suitable for demanding applications where greater torque is required.
Approx. Speed: 730 rpm
10 Pole
Maximum Torque Applications
For specialised applications requiring low speeds and exceptional torque.
Approx. Speed: 550 rpm
Mounting Options
The HM Series is available in a range of industry-standard mounting configurations, allowing the motor to integrate seamlessly into new installations or replace existing equipment with minimal modification.
Whether your application requires a foot-mounted motor for a base installation, a flange-mounted motor for direct equipment coupling, or a combination foot-and-flange configuration, the HM Series provides the flexibility to suit your system.
Available Configurations
Foot Mounted (B3)
Ideal for base-mounted equipment such as conveyors, pumps, compressors and general industrial machinery.
Foot & Flange Mounted (B35)
Combines the stability of foot mounting with the precision alignment of a flange, making it suitable for heavy-duty industrial applications.
Flange Mounted (B5)
Designed for direct coupling to pumps, gearboxes and driven equipment where compact installation and accurate shaft alignment are essential.
Face Mounted (B14A & B14B available)
Designed for compact equipment where installation space is limited. The small face flange provides precise alignment and direct mounting to pumps, gearboxes, machine tools and other close-coupled drive applications.
Advanced Cooling & Bearing Protection
Heat and inadequate lubrication are two of the biggest causes of premature electric motor failure. That's why the HM Series incorporates advanced cooling and bearing protection technologies that help extend service life, reduce maintenance and maximise reliability in demanding industrial environments.
Whether operating around the clock in a processing plant or under heavy loads in a mining application, these systems work continuously to protect the motor from the inside out.
TEFC Cooling
-
Removes excess heat
-
Protects against overheating, dust and moisture
-
Longer motor life
-
All industrial environments
Vibro Lube System
-
Maintains bearing lubrication
-
Prevents bearing wear and grease displacement
-
Reduced maintenance
-
High-vibration, heavy-duty applications
APPLICATIONS
No two industries operate under the same conditions, but every operation depends on reliable equipment.
From continuous production lines and critical water infrastructure to demanding mining applications, the HM Series is engineered to deliver dependable performance where it matters most.
Water & Sanitation
Water Pumps
Blowers
Aerators
Power and Utilities
Cooling Tower Fans
Boiler Feed Pump
Cooling Water Pumps
Manufacturing
Conveyor Systems
Packaging Machines
Production Lines
Agriculture
Irrigation pumps
Grain handling
Food and Beverage
Mixers
Conveyors
Packaging Machines
Mining
Crushers
Conveyors
Ventilation Fans
Petrochemicals
Refineries
Chemical Processing
Industrial and HVAC
Cooling Towers
Air Handling Units
